APL High-Speed Precision Automatic Punch Machine
High speed
High precision
High quality
Descripción
Performance Feature
Apply to precision electronic component punch in large quantity.
Enhance life if punch and mold under power balance device.
Oil-ressure slider fixed locking and sticking release device can increase reliability.
Cylinder connecting rod driving device can enhance of punch’s operation and precision.
Technical parameters
| Name | APL-25 | APL-45 | API-65 | ||||||
| Model | A B | C | A B | C | A | B | C | ||
| Capacity | ton | 25 | 45 | 65 | |||||
| Rated tonnage point(B.D.C | mm | 1.2 | 1.2 | 1.6 | |||||
| Stroke | mm | 20 30 | 40 | 20 30 | 40 | 20 | 30 | 40 | |
| Stroke per minute | s.p.m | 100-600 | 100-500 | 100-400 | 100-500/100-400 | 100-300 | 100-400 | 100-350 | 100-300 |
| Die height | mm | 225 220 | 215 | 265 260 255 | 305 | 300 | 295 | ||
| Bolster area(L.R.xF.B.) | mm | 650x390x75 | 760x450x90 | 860x52x100 | |||||
| Slide area(L.R.xF.B.) | mm | 280x250 | 380x320 | 460x370 | |||||
| Slide adjustment | mm | 30 | 30 | 50 | |||||
| Main motor | Kw | 3.7x4P | 5.5x4P | 7.5x4P | |||||
| Shank hole | mm | Φ38.1 | Φ50 | Φ50 | |||||
| Hole of bed (L.R.Xf.B.) | mm | 270x150 | 400x200 | 480X260 | |||||
| Lubrication system | Forced Recirculating Lubrication | ||||||||
