FU Type Horizontal / Pallet Decoiler
Lower gravity center and suitable for material loading
Material coil can be overlapped
Uncoiling speed reach 0-24m/min
Descripción
Horizontal / Pallet Decoiler
Description:
Save floor space, coil material loading time and increase production with this excellent LIHAO Electronically Controlled Pallet Reel. The FU's specialty is light gauge, thin material with narrow width, such as tab stock material for beverage cans, electrical parts and other related industries.
Feature:
Uniquely design with Japanese technology
Looping adjustment can reach "ZERO" tension
Coil width adjustment eliminated
Coil material head vertical controller
LED display and speed controller
Specification:
| Type | FU-500 | FU-1000 | FU-2000 |
| Material width | 100mm | 120mm | 150mm |
| Material thickness | 0.1-1.2mm | ||
| Max.Pallet weight | 500kg | 1000kg | 1500kg |
| Max.Table stacking height | 400mm | 600mm | 800mm |
| Max.Pallet Dia | 600mm | 800mm | 1000mm |
| Table speed range | 3.6-24m/min | ||
| Motor | 1/2HP | 1HP | 1HP |
Standard Accessory:
Coil material head up/down controller
LED display and speed controller
Emergency stop
